c
P44x/EN PL/Hb
MiCOM 40 Agile P442, P444
(PL) 6-
Ordinal English Text Description Source
178 CT Fail Alarm
Current transformers supervision indication: Indicates a
CT Fail detected after time delay has elapsed is issued
PSL (OUT)
CT
Supervision
241 Ctrl Cls In Prog
Manual (control) close in progress - using CB control
(time-delay manual closing delay in progress).
PSL (OUT)
CB Control
203 CVT Alarm
Alarm for capacitive voltage Transformer: Indicates the
residual voltage is greater than the threshold adjusted
in the settings, during a time-delay greater than the
adjustment. That alarm is also included in the general
alarm.
PSL (OUT)
274 DEF Fwd Channel Aided DEF: forward fault
PSL (OUT)
Aided DEF
273 DEF Rev Channel Aided DEF: reverse fault
PSL (OUT)
Aided DEF
271 DEF Sig. Send
DEF protection schemes - Signal Send
(Default PSL: Relay 05)
PSL (OUT)
Aided DEF
275 DEF Start A Channel Aided DEF: start phase A
PSL (OUT)
Aided DEF
276 DEF Start B Channel Aided DEF: start phase B
PSL (OUT)
Aided DEF
277 DEF Start C Channel Aided DEF: start phase C
PSL (OUT)
Aided DEF
1060 DEF Timer Block
Block aided DEF time delay
The DEF time-delay will be blocked & DEF will start but
will not issue any trip command.
Reset to 0: Opto input power off if signal assigned to
an opto input OR DDB at 0 if signal assigned to a DDB
cell
PSL (IN) DEF
278 DEF Trip A
Channel Aided DEF: trip phase A
Default PSL: Relay 09
PSL (OUT)
Aided DEF
279 DEF Trip B
Channel Aided DEF: trip phase B
Default PSL: Relay 09
PSL (OUT)
Aided DEF
280 DEF Trip C
Channel Aided DEF: trip phase C
Default PSL: Relay 09
PSL (OUT)
Aided DEF
272 DEF UNB CR
Unblocking DEF channel
internal Carrier Received signal (main Directional Earth
Fault unblocking signal) received.
PSL (OUT)
Unblocking
logic
1050 DEF. Chan Recv
Signal received on main channel for DEF scheme logic
(depending on settings: Aided DEF/Scheme logic)
Selected as shared by default – Can operate as an
independent scheme with a separate opto input from
Dist
Default PSL: Opto Label 1
PSL (IN) Un-
blocking logic
1052 DEF. COS
DEF scheme channel out of service / Loss of Guard
Selected shared by default – Can operate as an
independent scheme with a different opto input from
Dist
Default PSL: Opto Label 2
PSL (IN) Un-
blocking logic
345 DIST Convergency
Distance protection: Internal characteristic
Set to 1: logic with Distance Start at 1 (Minimum 1 loop
has been detected in the quadrilateral characteristic)
Set to 0: Reset of (R, X) (resistance, reactance)
calculation made by the All pole Dead detection
PSL (OUT)
Distance
244 DIST Fwd
Distance protection: Forward fault detected (default
PSL: LED6)
Set to 1: Directional Forward detected in distance
algorithms (Deltas or Conventional) AND (Distance
Start)
Set to 0: With reset of Any Start/Dist Start
PSL (OUT)
Distance
