44x/EN PL/Hb6
-44 MiCOM 40 Agile
Ordinal English Text Description Source
576 InterMiCOM in 1
InterMiCOM IM1 Signal Input - is driven by a message
from the remote line end
SW
577 to
583
InterMiCOM in 2 to
InterMiCOM in 8
InterMiCOM IM2 Signal Input to
InterMiCOM IM8 Signal Input
SW
584 InterMiCOM out 1
InterMiCOM IM1 Signal output - mapping what will be
sent to the remote line end
PSL
585 to
591
InterMiCOM out 2 to
InterMiCOM out 8
InterMiCOM IM2 Signal output to
InterMiCOM IM8 Signal output
PSL
481 IP Addr Conflict Ethernet IP Address Conflict alarm PSL(OUT)
640 LED 1
Hardware version J - Programmable LED n° 1 is
energized.
SW
641 LED 1 Grn
Hardware version K - Programmable Green LED n° 1
is energized
ANY TRIP A in the default PSL
SW
765 LED 1 Grn Condit
Hardware version K - Assignment of signal to drive
output LED 1 green
PSL
640 LED 1 Red
Hardware version K - Programmable Red LED n° 1 is
energized.
ANY TRIP A in the default PSL
SW
764 LED 1 Red Condit
Hardware version K - Assignment of signal to drive
output LED 1 red - To drive LED1 Yellow DDB 764 and
DDB 765 must be driven at the same time
PSL
659 LED 10 Grn Hardware version K - Programmable Green LED n° 10 SW
658 LED 10 Red Hardware version K - Programmable Red LED n° 10 SW
661 LED 11 Grn Hardware version K - Programmable Green LED n° 11 SW
660 LED 11 Red Hardware version K - Programmable Red LED n° 11 SW
663 LED 12 Grn Hardware version K - Programmable Green LED n° 12 SW
662 LED 12 Red Hardware version K - Programmable Red LED n° 12 SW
665 LED 13 Grn Hardware version K - Programmable Green LED n° 13 SW
664 LED 13 Red Hardware version K - Programmable Red LED n° 13 SW
667 LED 14 Grn Hardware version K - Programmable Green LED n° 14 SW
666 LED 14 Red Hardware version K - Programmable Red LED n° 14 SW
669 LED 15 Grn Hardware version K - Programmable Green LED n° 15 SW
668 LED 15 Red Hardware version K - Programmable Red LED n° 15 SW
671 LED 16 Grn Hardware version K - Programmable Green LED n° 16 SW
670 LED 16 Red Hardware version K - Programmable Red LED n° 16 SW
673 LED 17 Grn Hardware version K - Programmable Green LED n° 17 SW
672 LED 17 Red Hardware version K - Programmable Red LED n° 17 SW
675 LED 18 Grn Hardware version K - Programmable Green LED n° 18 SW
674 LED 18 Red Hardware version K - Programmable Red LED n° 18 SW
641 LED 2
Hardware version J - Programmable LED n° 2 is
energized.
SW
643 LED 2 Grn
Hardware version K - Programmable Green LED n° 2
is energized
ANY TRIP B in the default PSL
SW
767 LED 2 Grn Condit
Hardware version K - Assignment of signal to drive
output LED 2 green
PSL
642 LED 2 Red
Hardware version K - Programmable Red LED n° 2 is
energized
ANY TRIP B in the default PSL
SW
766 LED 2 Red Condit
Hardware version K - Assignment of signal to drive
output LED 2 red
PSL
642 LED 3
Hardware version J - Programmable LED n° 3 is
energized.
SW
