GE P444 - Page 365

Programmable Logi
c P44x/EN PL/Hb
6
MiCOM 40 Agile P442, P444
(PL) 6-
45
Ordinal English Text Description Source
645 LED 3 Grn
Hardware version K - Programmable Green LED n° 3
ANY TRIP C in the default PSL
SW
769 LED 3 Grn Condit
Hardware version K - Assignment of signal to drive
output LED 3 green
PSL
644 LED 3 Red
Hardware version K - Programmable Red LED n° 3
ANY TRIP C in the default PSL
SW
768 LED 3 Red Condit
Hardware version K - Assignment of signal to drive
output LED 3 red
PSL
643 LED 4
Hardware version J - Programmable LED n° 4 is
energized.
SW
647 LED 4 Grn
Hardware version K - Programmable Green LED n° 4
General Start in the default PSL
SW
771 LED 4 Grn Condit
Hardware version K - Assignment of signal to drive
output LED 4 green
PSL
646 LED 4 Red
Hardware version K - Programmable Red LED n° 4
General Start in the default PSL
SW
770 LED 4 Red Condit
Hardware version K - Assignment of signal to drive
output LED 4 red
PSL
644 LED 5
Hardware version J - Programmable LED n° 5 is
energized.
SW
649 LED 5 Grn
Hardware version K - Programmable Green LED n° 5
Z1+Aided Trip in the default PSL
SW
773 LED 5 Grn Condit
Hardware version K - Assignment of signal to drive
output LED 5 green
PSL
648 LED 5 Red
Hardware version K - Programmable Red LED n° 5
Z1+Aided Trip in the default PSL
SW
772 LED 5 Red Condit
Hardware version K - Assignment of signal to drive
output LED 5 red
PSL
645 LED 6
Hardware version J - Programmable LED n° 6 is
energized.
SW
651 LED 6 Grn
Hardware version K - Programmable Green LED n° 6
Dist Fwd in the default PSL
SW
775 LED 6 Grn Condit
Hardware version K - Assignment of signal to drive
output LED 6 green
PSL
650 LED 6 Red
Hardware version K - Programmable Red LED n° 6
Dist Fwd in the default PSL
SW
774 LED 6 Red Condit
Hardware version K - Assignment of signal to drive
output LED 6 red
PSL
646 LED 7
Hardware version J - Programmable LED n° 7 is
energized.
SW
653 LED 7 Grn
Hardware version K - Programmable Green LED n° 7
Dist Rev in the default PSL
SW
777 LED 7 Grn Condit
Hardware version K - Assignment of signal to drive
output LED 7 green
PSL
652 LED 7 Red
Hardware version K - Programmable Red LED n° 7
Dist Rev in the default PSL
SW
776 LED 7 Red Condit
Hardware version K - Assignment of signal to drive
output LED 7 red
PSL
647 LED 8
Hardware version J - Programmable LED n° 8 is
energized.
PSL
655 LED 8 Grn
Hardware version K - Programmable Green LED n° 8
Autoreclose Enable in the default PSL
SW
779 LED 8 Grn Condit
Hardware version K - Assignment of signal to drive
output LED 8 green
PSL
654 LED 8 Red
Hardware version K - Programmable Red LED n° 8
Autoreclose Enable in the default PSL
SW
