Ordinal English Text Description Source
778 LED 8 Red Condit
Hardware version K - Assignment of signal to drive
output LED 8 red
PSL
657 LED 9 Grn Hardware version K - Programmable Green LED n° 9 SW
656 LED 9 Red Hardware version K - Programmable Red LED n° 9 SW
656 LED Cond IN 1
Hardware version J - Assignment of signal to drive
output Function Key LED 1
PSL
657 LED Cond IN 2
Hardware version J - Assignment of signal to drive
output Function Key LED 2
PSL
658 LED Cond IN 3
Hardware version J - Assignment of signal to drive
output Function Key LED 3
PSL
659 LED Cond IN 4
Hardware version J - Assignment of signal to drive
output Function Key LED 4
PSL
660 LED Cond IN 5
Hardware version J - Assignment of signal to drive
output Function Key LED 5
PSL
661 LED Cond IN 6
Hardware version J - Assignment of signal to drive
output Function Key LED 6
PSL
662 LED Cond IN 7
Hardware version J - Assignment of signal to drive
output Function Key LED 6
PSL
663 LED Cond IN 8
Hardware version J - Assignment of signal to drive
output Function Key LED 7
PSL
1672 to
1677
LN1 Analog Alarm to
LN6 Analog Alarm
Relays with IEC 61850 9-2 Ethernet board only
(software version D5.x)
If two consecutive of any Logical Node frames have
not been received within the Merge Unit Delay set
parameter (time of silence in the reception of the
frame), the LN is “absent”
PSL
1688 to
1693
LN1 Async to
LN6 Async
Relays with IEC 61850 9-2 Ethernet board only
(software version D5.x)
Any Logical Node is synchronized with Internal (local)
synchronization
PSL
1680 to
1685
LN1 Test Mode to
LN6 Test Mode
Relays with IEC 61850 9-2 Ethernet board only
(software version D5.x)
Any Logical Node is in “Test Mode”
PSL
1704 to
1709
LN1 Val Fail to
LN6 Val Fail
Relays with IEC 61850 9-2 Ethernet board only
(software version D5.x)
The sample value (SV) transmitted status from the LN
is “failed”
PSL
1696 to
1701
LN1 Val Quest to
LN6 Val Quest
Relays with IEC 61850 9-2 Ethernet board only
(software version D5.x)
The sample value (SV) transmitted status from the LN
is “questionable”
PSL
188 Lockout Alarm
Lockout alarm: An alarm is issued with: ‘Man CB
Unhealthy’or no 'Check Sync OK' (CB conditioning) or
‘Man CB Cls Fail’ or ‘Man CB Fail Trip’ or 'F.F. Lock' or
'CB Op Time Lock' or 'CB Ops Lockout'
PSL (OUT)
331 Loss. Load Trip
Loss of load trip (in application without communication
scheme and a 3P Trip logic)
PSL (OUT)
Loss of load
191 Man CB Cls Fail Alarm CB fail for manual closing command PSL (OUT)
190 Man CB Trip Fail Alarm CB Fail for manual trip command PSL (OUT)
192 Man CB Unhealthy Alarm CB performed by unhealthy condition PSL (OUT)
