Ordinal English Text Description Source
64 Opto Label 01
OPTO ISOLATOR 1
Set to 1 when the opto input is energised for a
minimum time: 7ms (48Vdc), 10ms (universal) to be
validated by internal logic
To enable the selection of a setting group by state
change of the opto isolated logic inputs 1 and 2,
disconnect Opto inputs 01 and 02 in the PSL (Opto
inputs 01 and 02 must not be connected to any output
signal)
OPTO
65 Opto Label 02
OPTO ISOLATOR 2
Set to 1 when the opto input is energised for a
minimum time: 7ms (48Vdc), 10ms (universal) to be
validated by internal logic
To enable the selection of a setting group by state
change of the opto isolated logic inputs 1 and 2,
disconnect Opto inputs 01 and 02 in the PSL (Opto
inputs 01 and 02 must not be connected to any output
signal)
OPTO
66 to 95
Opto Label 03 to
Opto Label 32
OPTO ISOLATOR 3 to
OPTO ISOLATOR 32
Set to 1 when the opto input is energised for a
minimum time:7ms (48Vdc), 10ms (universal) to be
validated by internal logic
OPTO
350 Out Of Step
Start of an Out of Step Detection (1st cycle), The first
out of step cycle has been detected (Zlocus in/out with
the opposite R sign) & the « Out Of Step start » picks-
up
PSL (OUT)
352 Out Of Step Conf Out of Step Confirmed (number of cycles reached) PSL (OUT)
700 to
763
Output cond. 1 to
Output cond. 64
Input to Relay Output Conditioner PSL
367 PAP Pre Start
PAP (specific application) Picks up by voltage
detectors (timer initiated)
PSL (OUT)
366 PAP Pres IN
Residual current detected by PAP (specific application)
function
PSL (OUT)
363 PAP Start A Phase A Start with PAP (specific application) function PSL (OUT)
364 PAP Start B Phase B Start with PAP (specific application) function PSL (OUT)
365 PAP Start C Phase C Start with PAP (specific application) function PSL (OUT)
1089 PAP TeleT. Heath
PAP (specific application) Carrier Out of Service (DT
trip decision)
PSL(IN)
1088 PAP TeleTrip CR
PAP (specific application) Carrier Receive for
teletransmission
PSL(IN)
1090 PAP Timer Block
Timer Block for frozen every timer initiated with PAP
(specific application) function
PSL(IN)
359 PAP Trip A
Trip A Phase decision from PAP (specific application)
function
PSL (OUT)
360 PAP Trip B
Trip B Phase decision from PAP (specific application)
function
PSL (OUT)
361 PAP Trip C
Trip C Phase decision from PAP (specific application)
function
PSL (OUT)
362 PAP Trip IN
Trip decision from PAP (specific application) function
(Ground Fault detected)
PSL (OUT)
269 Power Swing
Power swing detected (3 single phase loop inside the
quad & crossing the ∆R band in less than 5ms in a 50
Hz network). Power swing is present either with out of
step cycle or stable swing cycle.
PSL (OUT)
Distance
175 Prot'n Disabled Protection is disabled and test mode enabled PSL (OUT)
1480 to
1543
PubPres VIP 1 to
PubPres VIP 64
Publishing presence of virtual input 1 (to 64): indicates
virtual input 1 (to 64) presence.
PSL
1353 to
1415
Quality VIP 1 to
Quality VIP 64
Validation of the virtual input 1 (to 64)
(signal correct).
PSL
