P44x/EN PL/Hb
MiCOM 40 Agile P442, P444
(PL) 6-
Ordinal English Text Description Source
0 to 63
Relay Label 01 to
Relay Label 64
OUTPUT RELAY 1 to
OUTPUT RELAY 64
High level when a DDB cell (linked by PSL logic) is at
1. State depends on the logic set in the PSL (MiCOM
S1 Agile)
These programmable relays are assigned in the default
PSL, with the following logic conditions (see section
1.8.2):
- Pulse time-delay
- Pick Up/Drop Off Time-delay
- Dwell Time-delay
- Pick Up Time-delay
- Drop Off Time-delay
- Latching
- Straight (used in default PSL)
RELAY
1081 Reset All values
Reset all values of CB monitoring (all counters and
values are reset ('CB condition')
PSL (IN) CB
Monitoring
1082 Reset Latches
Reset all permanent alarms + LEDs and relays are
latched
PSl (IN)
1080 Reset Lockout
Reset all CB monitoring lockout (all counters and
values are reset ('CB condition')
PSL (IN) CB
Monitoring
1091 Reset Thermal Reset Thermal Overload Protection PSL(IN)
270 Reversal Guard
Current reversal guard logic in action
(Directional switching from Rev to Fwd in parallel line
application)
PSL (OUT)
Distance
1112 RP1 Read Only
All setting changes and most command/control actions
blocked for Rear Port 1.
PSL
1113 RP2 Read Only
All setting changes and most command/control actions
blocked for Rear Port 2.
PSL
351 S. Swing
Start of Stable Swing (1st cycle): The first stable swing
cycle has been detected (Zlocus in/out with the same
R sign) & the « Stable Swing start » picks-up
PSL (OUT)
353 S. Swing Conf Stable Swing confirmed (number of cycles reached) PSL (OUT)
437 SBO Closed Org 1
Select Before Operate (SBO) closing function for
organ 1 (interlocking facility in the IEC 60870-5-103
protocol)
PSL
438 SBO Closed Org 2
Select Before Operate (SBO) closing function for organ
2 (interlocking facility in the IEC 60870-5-103 protocol)
PSL
439 SBO Closed Org 3
Select Before Operate (SBO) closing function for organ
3 (interlocking facility in the IEC 60870-5-103 protocol)
PSL
440 SBO Closed Org 4
Select Before Operate (SBO) closing function for organ
4 (interlocking facility in the IEC 60870-5-103 protocol)
PSL
1118 SBO Command1 SBO support for IEC 61850-8-1 function command 1 PSL
1122 SBO Command2 SBO support for IEC 61850-8-1 function command 2. PSL
1126 SBO Command3 SBO support for IEC 61850-8-1 function command 3 PSL
1130 SBO Command4 SBO support for IEC 61850-8-1 function command 4. PSL
1116 SBO DPI1 Org1
SBO support for IEC 61850-8-1 function. SBO Double
Point Information 1 Organe 1
PSL
1120 SBO DPI1 Org2
SBO support for IEC 61850-8-1 function. SBO Double
Point Information 1 Organe 2
PSL
1124 SBO DPI1 Org3
SBO support for IEC 61850-8-1 function. SBO Double
Point Information 1 Organe 3
PSL
1128 SBO DPI1 Org4
SBO support for IEC 61850-8-1 function. SBO Double
Point Information 1 Organe 4
PSL
1117 SBO DPI2 Org1
SBO support for IEC 61850-8-1 function SBO Double
Point Information 2 Organe 1
PSL
1121 SBO DPI2 Org2
SBO support for IEC 61850-8-1 function SBO Double
Point Information 2 Organe 2
PSL
