44x/EN PL/Hb6
-50 MiCOM 40 Agile
Ordinal English Text Description Source
1125 SBO DPI2 Org3
SBO support for IEC 61850-8-1 function SBO Double
Point Information 2 Organe 3
PSL
1129 SBO DPI2 Org4
SBO support for IEC61850-8-1 function SBO Double
Point Information 2 Organe 4
PSL
1115 SBO InterLock 1
SBO support for IEC 61850-8-1 control function with
interlocking facilities 1
PSL
1119 SBO InterLock 2
SBO support for IEC 61850-8-1 control function with
interlocking facilities 2
PSL
1123 SBO InterLock 3
SBO support for IEC 61850-8-1 control function with
interlocking facilities 3
PSL
1127 SBO InterLock 4
SBO support for IEC61850-8-1 control function with
interlocking facilities 4
PSL
433 SBO Open Org 1
Select Before Operate (SBO) opening function for
organ 1 (interlocking facility in the IEC 60870-5-103
protocol)
PSL
434 SBO Open Org 2
Select Before Operate (SBO) opening function for
organ 2 (interlocking facility in the IEC 60870-5-103
protocol)
PSL
435 SBO Open Org 3
Select Before Operate (SBO) opening function for
organ 3 (interlocking facility in the IEC60870-5-103
protocol)
PSL
436 SBO Open Org 4
Select Before Operate (SBO) opening function for
organ 4 (interlocking facility in the IEC 60870-5-103
protocol)
PSL
1093 Select CS(NCIT) Select Check synchro for NCIT PSL
195 SG-opto Invalid Setting group (selected via opto inputs 1 & 2) invalid PSL (OUT)
312 SOTF Enable
Switch On To Fault enabled: Indicates the SOTF logic
is enabled in the relay
Set to 1 = [SOTF not disabled (Setting 'Distance
schemes /
TOR-SOTF Mode')]
AND [ { All poles dead AND (SOTF time-
delay elapsed
(110 s/default)) }
OR Input Man Close]
OR (CB control & Close in progress)]
Reset = 500ms time-delay elapsed after Any
pole Dead
OR Reset of one condition requested for SOTF
enable
PSL (OUT)
SOTF
332 SOTF/TOR Trip
Switch on to fault trip or trip on reclose: indicates that a
3-pole trip order has been issued by the TOR or SOTF
logic
PSL (OUT)
SOTF
1031 SPAR Enable
Enable internal single pole autorecloser.
Set with Opto input (if linked by PSL) is energized (>
1s).
At 1: 1P AR internal is enabled in the AR logic
At 0: AR 1P internal is disabled (even if set in MiCOM
S1 Agile). AR logic becomes 3P only with AR 3P cycle
-if TPAR =1
PSL (IN)
Autorecloser
1083 Stub Bus Enable
Enable I>4 Element for stub bus protection (isolator of
HV line open - status isolator must be connected to an
opto input)
PSL (IN)
207 Synchro Acq Al.
Relays with IEC 61850 9-2 Ethernet board only with
software version up to D4.x - Any Logical Node is
synchronized with external (global) synchronization
PSL (OUT)
261 T1
Distance time-delay in zone 1 tZ1 elapsed (1 = end of
timer)
If T1=0 picks up when the relay starts (Distance Start
or preset)
PSL (OUT)
Distance
1094 T1 Timer Block Timer block T1 input PSL
