Ordinal English Text Description Source
262 T2
Distance time-delay in zone 2 tZ2 elapsed (1 = end of
timer)
PSL (OUT)
Distance
1095 T2 Timer Block Timer block T2 input PSL
263 T3
Distance time-delay in zone 3 tZ3elapsed (1 = end of
timer)
PSL (OUT)
Distance
1098 T3 Timer Block Timer block T3 input PSL
264 T4
Distance time-delay in zone 4 tZ4 elapsed (1 = end of
timer)
PSL (OUT)
Distance
1099 T4 Timer Block Timer block T4 input PSL
333 tBF1 Trip
Circuit Breaker failure on any trip, delayed by "CB Fail
1 Timer" (setting in "CB Fail" logic)
PSL (OUT)
Breaker
failure
334 tBF2 Trip
Circuit Breaker failure on any trip, delayed by "CB Fail
2 Timer" (setting in "CB Fail" logic)
PSL (OUT)
Breaker
failure
206 Test Mode Acq
Relays with IEC 61850 9-2 Ethernet board only with
software version up to D4.x - Any Logical Node is in
“Test Mode”
PSL (OUT)
369 Thermal Alarm Alarm from Thermal Overload function picks up PSL (OUT)
1092 Time Synch External time synchronisation input PSL(IN)
830 to
845
Timer in 1 to
Timer in 16
Hardware version K - PSL Input to Auxiliary Timer 1
to PSL Input to Auxiliary Timer 16
Auxiliary
Timer
830 to
861
Timer in 1 to
Timer in 16
Hardware version J - PSL Input to Auxiliary Timer 1
to PSL Input to Auxiliary Timer 32
Auxiliary
Timer
862 to
893
Timer in 1 to
Timer in 16
Hardware version J - PSL Output from Auxiliary Timer
1
to PSL Output from Auxiliary Timer 32
Auxiliary
Timer
846 to
861
Timer out 1 to
Timer out 16
Hardware version K - PSL Ouput from Auxiliary Timer
1
PSL Ouput from Auxiliary Timer 16
Auxiliary
Timer
314 TOC Start A
Trip on Close start on phase A: indicates a trip order
on phase A has been issued by the SOTF level
detectors
(Pickup time-delay = 20 ms)
PSL (OUT)
SOTF
315 TOC Start B
Trip on Close start on phase B: indicates a trip order
on phase B has been issued by the SOTF level
detectors
(Pickup time-delay = 20 ms)
PSL (OUT)
SOTF
316 TOC Start C
Trip on Close start on phase C: indicates a trip order
on phase C has been issued by the SOTF level
detectors (
Pickup time-delay = 20 ms)
PSL (OUT)
SOTF
313 TOR Enable
Trip On Reclose enable: indicates the TOR logic is
activated in the relay
Set to 1= 500 ms pulse initiated by:
'I A/R Reclaim' (internal) OR 'A/R reclaim' (External
Input)
OR Any pole open for more than 200 ms
Reset 500 ms after Any pole dead stops
PSL (OUT)
TOR
1032 TPAR Enable
Enable internal three pole autorecloser
Set with Opto input (if linked by PSL) is energized (>
1s).
At 1: 3P AR internal is enabled in the AR logic
At 0: AR 3P internal is disabled (even if set in MiCOM
S1 Agile). 1P cycle available if SPAR =1
PSL (IN)
Autorecloser
368 Trace Trig OK Triggering trace has operated correctly PSL (OUT)
1024 Trip LED LED trip
370 Trip Thermal Trip with Thermal Overload fucntion (timer issued) PSL (OUT)
265 Tzp
Distance time-delay in zone p tZp elapsed (1 = end of
timer)
PSL (OUT)
Distance
1096 TZp Timer Block Timer block TZp input PSL
