GE P444

P
44x/EN ST/Hb6
Setting
(ST) 4
-8 MiCOM P40 Agile
P442, P444
Menu text Default setting Available settings
CONFIGURATION
Copy From Group 1 Group1,2,3 or 4
Allows displayed settings to be copied from a selected setting group.
Copy To No Operation No Operation / Group1, 2, 3 or 4
Allows displayed settings to be copied to a selected setting group (ready to paste).
Setting Group 1 Enabled Enabled or Disabled
If the setting group is disabled from the configuration, then all associated settings and
signals are hidden, with the exception of this setting (paste).
Setting Group 2 Disabled Enabled or Disabled
Setting Group 3 Disabled Enabled or Disabled
Setting Group 4 Disabled Enabled or Disabled
Distance Protection Enabled Enabled or Disabled
To enable (activate) or disable (turn off) the Distance Protection.
Power Swing Enabled Enabled or Disabled
To enable (activate) or disable (turn off) the power swing blocking / out of step.
Back-up I> Disabled Enabled or Disabled
To enable (activate) or disable (turn off) the directional or non-directional overcurrent
protection.
Neg Sequence O/C Disabled Enabled or Disabled
To enable (activate) or disable (turn off) the Negative sequence overcurrent protection.
Broken Conductor Disabled Enabled or Disabled
To enable (activate) or disable (turn off) the Broken Conductor detection.
Earth Fault O/C Prot Disabled Enabled or ‘Zero Seq. power’ or ‘Earth
Fault O/C’
To enable (activate) or disable (turn off) the earth fault overcurrent protection. Two earth
fault overcurrent protections are available:
– Directional and non-directional earth fault overcurrent protection (‘Earth Fault O/C’),
– Maximum of Residual – Zero Sequence power protection (‘Zero Seq. power’).
Earth fault prot (ZSP) Disabled Enabled or Disabled
To enable (activate) or disable (turn off) the earth fault protection function (IN>stages)
Aided DEF Enabled Enabled or Disabled
To enable (activate) or disable (turn off) the Aided directional earth fault protection.
Volt Protection Disabled Enabled or Disabled
To enable (activate) or disable (turn off) the voltage protection (under / overvoltage)
function.
CB Fail & I< Enabled Enabled or Disabled
To enable (activate) or disable (turn off) the circuit breaker fail protection function.
Supervision Enabled Enabled or Disabled
To enable (activate) or disable (turn off) the Supervision (VTS, CTS and CVT) functions.
System Checks Disabled Enabled or Disabled
To enable (activate) or disable (turn off) the check synchronisation (System check) menu.
