Fault Location Fields for Faults in Local Log Table
When displaying the detailed view of a fault on the PROFINET Controller, the Fault Location
field contents vary, depending on the exact type and location of the fault being logged. The
table below shows the possible fault locations along with the expected display formats.
Fault Location
Format of Fault Location Field
Description
PROFINET
Controller
<Rack>.<Slot>
PROFINET Controller in rack #<Rack> and slot
#<Slot> logged its own fault.
Profinet Device
<Rack>.<Slot>.D<Device>
PROFINET Controller in rack #<Rack> and slot
#<Slot> logged a fault for Profinet Device
#<Device>.
Profinet Module
<Rack>.<Slot>.D<Device>.r
<RemoteRack>.s<RemoteSlot>
PROFINET Controller in rack #<Rack> and slot
#<Slot> logged a fault for the module located in
rack #<RemoteRack> and slot #<RemoteSlot> of
Profinet IO Device #<Device>.
Profinet
Submodule
<Rack>.<Slot>.D<Device>.
r<Remote Rack>.
s<RemoteSlot>.
ss<RemoteSubslot>
PROFINET Controller in rack #<Rack> and slot
#<Slot> logged a fault for the sub-module located
in rack #<RemoteRack>, slot #<RemoteSlot>,
and subslot #<RemoteSubslot> of Profinet IO
Device #<Device>.
Profinet
Interface
<Rack>.<Slot>.D<Device>.
r<RemoteRack>. s<RemoteSlot>.
i<Interface>
PROFINET Controller in rack #<Rack> and slot
#<Slot> logged a fault for the interface in rack
#<RemoteRack>, slot #<RemoteSlot>, and
interface #<Interface> of Profinet IO Device
#<Device>.
Profinet
Interface Port
<Rack>.<Slot>.D<Device>.
r<RemoteRack>.
s<RemoteSlot>.i<Interface>.
p<Port>
PROFINET Controller in rack #<Rack> and slot
#<Slot> logged a fault for the interface port in
rack #<RemoteRack>, slot #<RemoteSlot>,
interface #<Interface>, and port #<Port> of
Profinet IO Device #<Device>.
