GFK-1504K Chapter 5 Interposing Terminals and Auxiliary I/O Terminal Strips 5-9

IC200CHS015

Spring-Style Interposing I/O Terminals

Din Rail Mounting

The Interposing I/O Terminals can be mounted on the same DIN rail as the Connector-

Style I/O Carrier, or on a separate DIN rail as illustrated below. For applications requiring

maximum resistance to mechanical vibration and shock, the Interposing I/O Terminals

must also be panel-mounted. See chapter 2 for installation instructions.
