The following table provides a guideline for selecting the appropriate bases and wiring
formats for VersaMax I/O modules. Modules that are incompatible with these Interposing
Disconnect Bases are indicated by shaded entries in the table.
1 Group
/Row
2 Groups
/Row
Not
Grouped
CHS101 CHS102 Notes
Discrete Inputs
IC200MDL140 X* X See below.
IC200MDL141 X* X See below.
IC200MDL143 X X
IC200MDL144 Module not compatible with VersaMax Connector Base
IC200MDL240 X* X X See below.
IC200MDL241 X* X X See below.
IC200MDL243 X X X
IC200MDL244 Module not compatible with VersaMax Connector Base
IC200MDL631 X X
IC200MDL632 X X X
IC200MDL635 X X
IC200MDL636 X X X
IC200MDL640 X X
IC200MDL643 X X
IC200MDL644 X X X
IC200MDL650 X X X
Discrete Outputs
IC200MDL329 X X
IC200MDL330 X X X
IC200MDL331
IC200MDL730
No direct connectivity to B row
IC200MDL740 X X
IC200MDL741 X X
IC200MDL742 X X X
IC200MDL743 X X
IC200MDL744 X X X
IC200MDL750 X X X
IC200MDL930 X X
IC200MDL940 X X X
Discrete Mixed
IC200MDD840 Non-symmetric distribution of inputs & outputs
IC200MDD842 X X X X 1 Group/Row, Outputs, 2 Groups/Row, Inputs
IC200MDD843 Non-symmetric distribution of inputs & outputs
IC200MDD844 X X X X
IC200MDD845 X X X X
1 Group/Row for Outputs, 2 Groups/Row for
Inputs
IC200MDD846 X* X X X
IC200MDD847 X* X X X
IC200MDD848 X* X X X
Not Grouped for Outputs, 1 Group/Row for
Inputs. See below.
IC200MDD849 X X X
IC200MDD850 Module not compatible with VersaMax Connector Base
IC200MDD851 X X X X 1 Group/Row, Outputs. 2 Groups/Row, Inputs
*
Variation of the one-group per row format - return groups W & X should be jumpered to terminal A17.
