C-2 VersaMax® Modules, Power Supplies, and Carriers User's Manual – March 2003 GFK-1504K
C
Power Supply Capacities
The Power Supply on the CPU or NIU module provides +5V and +3.3V power to the
modules in the station. Booster Power Supplies can be used if the modules in the system
will draw more current than the CPU or NIU Power Supply can provide. The AC or DC
Power Supply on the CPU or NIU and the Power Supply that resides on the Booster
Carrier must share the same external power source.
For each Power Supply, the maximum total combined output current from the 5V and
3.3V outputs is 1.5 Amps. Each power supply provides a maximum of either 0.25 Amp or
1 Amp on its 3.3V output, as listed in the next table. That portion of the Power Supply’s
total output current not drawn from the 3.3V output is available via the 5.5V output.
Maximum Output Current in AmpsCatalog
Number
Description
Total
(5V + 3.3V)
5V 3.3V
IC200PWR001 24VDC Power Supply 1.5A (1.5A – I
3.3V
) 0.25A
IC200PWR002 24VDC Expanded 3.3V Power Supply 1.5A (1.5A – I
3.3V
)1.0A
IC200PWR101 120/240VAC Power Supply 1.5A (1.5A – I
3.3V
) 0.25A
IC200PWR102 120/240VAC Expanded 3.3V Power Supply 1.5A (1.5A – I
3.3V
)1.0A
IC200PWR201 12VDC Power Supply 1.5A (1.5A – I
3.3V
) 0.25A
IC200PWR202 12VDC Expanded 3.3V Power Supply 1.5A (1.5A – I
3.3V
)1.0A
Power Calculation Example
In the example system listed below, the maximum current draw on the Power Supply’s
3.3V output by all of the modules will be 0.215 Amp.
Subtracting 0.215A from the Power Supply total output of 1.5A shows that 1.285A will be
available via the 5.5V output:
(1.5A – 0.215A = 1.285A)
Because the maximum current draw on the 5V output would be 0.65A as shown in the
table below, any of the available Power Supplies could be used for this system.
Catalog
Number
Description Backplane Current
Consumption in mA
5V 3.3V
IC200CPU001
CPU with 2 serial ports, with EZ Program Store device
140 100
IC200ALG261
Analog Input Module, 15 Bit Voltage Differential 8 Channels
200
IC200ALG327 Analog Output Module, 13 Bit Voltage 12 Channels 50
IC200ALG331 Analog Output Module, 16 Bit Voltage/Current, 1500VAC
Isolation, 4 Channels
10 115
IC200MDL650 Input Module, 24VDC Positive/Negative Logic 32 Points 50
IC200MDL650 Input Module, 24VDC Positive/Negative Logic 32 Points 50
IC200MDL742 Output Module, 24VDC Positive Logic 0.5 Amp, w/ESCP 32 Pts 150
Total Current Required by Modules 650mA
(0.65A)
215mA
(0.215A)
