2-22 VersaMax® Modules, Power Supplies, and Carriers User's Manual – March 2003 GFK-1504K
2
Terminal Assignments for Cable IC200CBL230
The tables that follow show terminal assignments for cable IC200CBL230. Cable
IC200CBL230 is available in two cable types. They are functionally equivalent. The cable
type is marked on the cable.
“Belden” Cable Terminal Assignments
Terminal Block Position Base color 1
st
spot 2
nd
spot terminal # wire #
A1 Black 36 32
A2 Black Red 35 34
A3 Black White Green 34 23
A4 Orange Red 33 11
A5 Red Green 32 36
A6 Blue Red 25 16
A7 Black White Orange 24 22
A8 Green White 23 38
A9 Red Black Green 22 10
A10 Blue White 21 13
A11 Blue White Orange 15 37
A12 Orange Black Green 14 21
A13 Green Black Orange 13 9
A14 Blue Black 12 12
A15 Black Red Green 11 30
A16 Blue Black White 10 24
A17 White Red 4 7
A17 White Black Red 4 8
A18 White 3 5
A18 White Red Green 3 6
B1 Red Black 27 35
B2 Red 26 33
B3 Red White Green 29 17
B4 Black White Red 28 18
B5 Orange White Blue 31 19
B6 Orange Green 30 15
B7 Green 17 14
B8 Orange Black 16 27
B9 Green Black 19 29
B10 Orange 18 40
B11 Red Black White 5 31
B12 Red White 20 39
B13 Orange Black White 7 26
B14 Green Black White 6 25
B15 Blue 9 28
B16 Black White 8 20
B17 White Black Green 2 3
B17 White Black 2 4
B18 White Red Blue 1 1
B18 White Red Orange 1 2
