GE VersaMax

GFK-1504K Chapter 2 Installation Instructions 2-23
2
“Alpha” Cable Terminal Assignments
Terminal Block Position Base color 1st stripe 2nd stripe terminal # wire #
A1 White Brown Blue 36 32
A2 White Brown Gray 35 34
A3 White Black Yellow 34 23
A4 White Black 33 11
A5 White Red Yellow 32 36
A6 White Green 25 16
A7 White Black Orange 24 22
A8 White Red Blue 23 38
A9 White 22 10
A10 White Red 21 13
A11 White Red Green 15 37
A12 White Black Red 14 21
A13 Gray 13 9
A14 White Brown 12 12
A15 White Brown Yellow 11 30
A16 White Black Green 10 24
A17 Blue 4 7
A17 Violet 4 8
A18 Yellow 3 5
A18 Green 3 6
B1 White Red Orange 27 35
B2 White Brown Violet 26 33
B3 White Blue 29 17
B4 White Violet 28 18
B5 White Gray 31 19
B6 White Yellow 30 15
B7 White Orange 17 14
B8 White Black Gray 16 27
B9 White Brown Orange 19 29
B10 White Red Gray 18 40
B11 White Brown Green 5 31
B12 White Red Violet 20 39
B13 White Black Violet 7 26
B14 White Black Blue 6 25
B15 White Brown Red 9 28
B16 White Black Brown 8 20
B17 Red 2 3
B17 Orange 2 4
B18 Black 1 1
B18 Brown 1 2
