IC200ERM001
Expansion Receiver Module, Isolated
Module Specifications
Module Characteristics
Module ID
LED indicators PWR LED indicates 5VDC power status
EXP RX LED indicates status of the expansion bus
SCAN indicates whether CPU/NIU is scanning I/O in expansion racks
Backplane current
consumption
5V output: 430mA maximum. 3.3V output: 20mA
Cable Specifications
Maximum cable length
Effective data rate
Electrical Isolation
250 meters (if configured for higher data rate)
750 meters (default distance)
1 Mbits/sec (configurable for cable less than 250 meters)
250 Kbits/sec (default data rate)
500 VDC isolated differential communications
Catalog Numbers
Bus Receiver Module IC200ERM001
Bus Transmitter Module
Expansion Cable
Firmware Update Cable
Terminator Plug
Connector Kit
IC200ETM001
IC200CBL601 - 1 meter
IC200CBL602 - 2 meters
IC200CBL615 - 15 meters
IC200CBL002
IC200ACC201 (included with ETM)
IC200ACC202
Compatibility
All I/O and communications modules can be used in expansion racks. Some analog
modules require specific module revisions as listed below. The date code is a 3-digit
number on the outside of the module and on the shipping box.
Module Module
Revision
Module Date Code Range
IC200ALG320 B or later Any
IC200ALG321 B or later Any
IC200ALG322 B or later Any
IC200ALG430 C or later Any
IC200ALG431 C or later Any
IC200ALG432 B or later Any
A or later
CPU or NIU Revision 1.5:
Date code must begin with a number
other than 9 and must be 011 or greater.
IC200ALG230
Any
CPU or NIU Revision 2.0 or later:
Any date code.
A or later
CPU or NIU Revision 1.5:
Date code must begin with a number
other than 9 and must be 011 or greater.
IC200ALG260
Any
CPU or NIU Revision 2.0 or later:
Any date code.
