IC200CHS002

Box-Style I/O Carrier

The Box-Style I/O Carrier (IC200CHS002) has 36 IEC box-style terminals. It provides

mounting, backplane communications, and field wiring for one I/O module.

110.5mm

(4.35in)

139.7mm

(5.5in)

IND CONT EQ FOR HAZ LOC

CLASS I DIV 2 GROUPS ABCD

Ambient 60C

CLASS 1 ZONE 2 GROUP IIC

Ex nA IIC 0C <To<60C

Ex nV II Demko No. 98Y.125014

IC200CHS002

I/O CARRIER

BOX STYLE

The I/O module mounts lengthwise (parallel to the DIN rail) on this carrier.
