8-10 VersaMax® Modules, Power Supplies, and Carriers User's Manual – March 2003 GFK-1504K

IC200MDL331

Output Module, 120VAC 2.0 Amp, Isolated 8 Points

Discrete output module IC200MDL331 provides 8 isolated outputs.

1234567 814

IND CONT EQ FOR HAZ LOC

CLASS I DIV 2 GROUPS ABCD

Ambient 60C

CLASS I ZONE 2 GROUP IIC

Ex nA IIC 0C

≤

60C

Ex nV Demko No. 98Y. 125014

IC200MDL331

OUTPUT 120VAC

ISO 2A 8PT

1 2 3 456 78

An external 120 VAC power supply must be provided to switch power to the loads.

Intelligent processing for this module is performed by the CPU or NIU. The module

receives 8 bits of discrete output data.

LED Indicators

Individual green LEDs indicate the on/off state of the output points. The output

LEDs are logic-driven and independent of the load conditions.

The green OK LED is on when backplane power is present to the module.
