GFK-1504K Chapter 7 Discrete Input Modules 7-3
7
IC200MDL140
Input Module, 120VAC 8 Points
Module Specifications
Module Characteristics
Points One group of 8 inputs
Module ID FFFF8804
Isolation:
User input to logic (optical)
and frame ground
Group to group
Point to point
250VAC continuous; 1500VAC for 1 minute
Not applicable
None
LED indicators One LED per point shows individual point ON/OFF status
OK LED indicates backplane power is present
Backplane current
consumption
5V output: 55mA maximum
External power supply None
Thermal derating None
Input Characteristics
Input voltage 0 to 132VAC (47 to 63Hz), 120VAC nominal
On state voltage
Off state voltage
70 to 132VAC
0 to 20VAC
On state current
Off state current
5mA minimum
2.5mA maximum
On response time
Off response time
1 cycle maximum
2 cycles maximum
Input impedance 8.6kOhms (reactive) at 60Hz, typical
10.32kOhms (reactive) at 50Hz, typical
