GFK-1504K Chapter 7 Discrete Input Modules 7-39
7
IC200MDL636
Input Module, 48VDC Pos/Neg Logic Grouped 32 Points
Module Specifications
Module Characteristics
Points 32 (4 groups of 8)
Module ID 80088008
Isolation:
User input to logic (optical)
and to frame ground
Group to group
Point to point
250VAC continuous; 1500VAC for 1 minute
250VAC continuous; 1500VAC for 1 minute
None
LED indicators One LED per point shows individual point ON/OFF
status
OK LED indicates backplane power is present
Backplane current consumption 5V output: 140mA maximum
External power supply None
Thermal derating See diagram
Configuration parameters Input response times
Input Characteristics
Input voltage 0 to 60VDC, 48VDC nominal
User input current 1.7mA typ. @ 48VDC, 2.1mA typ. @ 60VDC
Input impedance 28K Ohm typ.
On state voltage 34VDC to 60VDC
Off state voltage 0 VDC to 10VDC
On state current
Off state current
1.0mA minimum
0 to 0.4mA maximum
On response time
Off response time
0.5ms maximum
Configurable filter time 0 ms, 1.0ms (default), or 7.0ms
