IC200MDL643
Input Module, 5/12VDC Pos/Neg Logic Grouped 16 Points
Module Specifications
Module Characteristics
Points 16 inputs (2 groups of 8)
Module ID FFFF8008
Isolation:
User input to logic (optical)
and to frame ground
Group to Group
Point to point
250VAC continuous; 1500VAC for 1 minute
250VAC continuous; 1500VAC for 1 minute
None
LED indicators One LED per point shows individual point ON/OFF status
OK LED indicates backplane power is present
Backplane current
consumption
5V output: 70 mA maximum
External power supply None
Thermal derating No derating
Configuration parameters Input response times
Input Characteristics
Input voltage 0 to +15VDC, +5/12 VDC nominal
User input current 1.8mA typ. @ 5VDC, 4.9mA typ. @ 12VDC
Input impedance 2.4K Ohm typ. @ 12VDC
On state voltage +4.2 to +15VDC
Off state voltage 0 to +2.6VDC
On state current
Off state current
1.45mA minimum
0 to 0.7mA maximum
On response time
Off response time
0.25ms maximum
Configurable filter time 0ms, 1.0ms (default), or 7.0ms
