7-52 VersaMax® Modules, Power Supplies, and Carriers User's Manual – March 2003 GFK-1504K

IC200MDL644

Input Module, 5/12VDC Pos/Neg Logic Grouped 32 Point

Wiring for TTL Inputs

To be compatible with TTL outputs, the negative logic configuration should be used

as shown below.

Input x

Output

TTL IC

Common x

+5V

User

Circuit
