GFK-1504K Chapter 9 Discrete Mixed Modules 9-3
9
IC200MDD840
Mixed Module, 24VDC Positive Logic Input 20 Points /
Output Relay 2.0 Amp 12 Points
Module Specifications
Module Characteristics
Points 20 positive DC inputs, two groups of 10
12 Form A relay outputs, two groups of 6
Module ID 80358035
Isolation:
User input/output to logic
(optical) and frame ground
Group to group
Point to point
250VAC continuous; 1500VAC for 1 minute
250VAC continuous; 1500VAC for 1 minute
None
LED indicators One LED per point shows individual point on/off state
OK LED indicates backplane power is present
Backplane current consumption 5V output: 375mA maximum
External power supply 0 to 125VDC, 5/24/125VDC nominal
0 to 265VAC (47 to 63Hz), 120/240VAC nominal
Thermal derating None
Configuration parameters Input response time
Input Characteristics
Input voltage 0 to +30VDC, +24VDC nominal
On state voltage
Off state voltage
+15 to +30VDC
0 to +5VDC
On state current
Off state current
2.0 to 5.5mA
0 to 0.5mA
On response time
Off response time
0.5ms maximum
Configurable filter time 0ms, 1.0ms (default), or 7.0ms
Input impedance 10kOhms, maximum
Output Characteristics
Output voltage 0 to 125VDC, 5/24/125VDC nominal
0 or 265VAC (47 to 63Hz), 120/240VAC nominal
Output voltage drop 0.3V maximum
Load current 10mA per point minimum
2.0A for 5 to 265VAC maximum (resistive), 8.0A max. per group
2.0A for 5 to 30VDC maximum (resistive), 8.0A max. per group
0.2 A for 31 to 125VDC maximum (resistive)
Output leakage current Not applicable (open contact)
On response time
Off response time
10ms maximum
10ms maximum
Protection No internal fuses or snubbers
Switching frequency 20 cycles per minute (inductive load)
Relay type Fixed coil, moving armature
Contact type Silver alloy
Contact life See appendix B
