GFK-1504K Chapter 9 Discrete Mixed Modules 9-17
9
IC200MDD844
Mixed Module, Output 12/24VDC Pos. Logic 0.5A 16 Points
/ Input 24 VDC Pos/Neg Logic Grouped 16 Points
Module Specifications
Module Characteristics
Points 1 group of 16 outputs
2 groups of 8 inputs
Module ID 80088080
Isolation:
User input to logic (optical) and to
frame ground
Group to group
Point to point
250VAC continuous; 1500VAC for 1 minute
250VAC continuous; 1500VAC for 1 minute
None
LED indicators One LED per point shows individual point on/off state
FLD PWR LED indicates field power is present
OK LED indicates backplane power is present
Backplane current consumption 5V output: 70mA maximum
External power supply +10.2 to +30VDC, +12/24VDC nominal
Thermal derating See diagram
Configuration parameters Input response time
Input Characteristics
Input voltage 0 to +30VDC, +24VDC nominal
On state voltage +15 to +30VDC
Off state voltage 0 to +5VDC
On state current
Off state current
2.0 to 5.5mA
0 to 0.5mA
On response time
Off response time
0.5ms maximum
Configurable filter time 0 ms, 1.0ms (default), or 7.0ms
Input impedance 10kOhms maximum
Output Characteristics
Output voltage +10.2 to +30VDC, +12/24VDC nominal
Output voltage drop 0.3V
Load current 0.5 Amp at 30VDC maximum (resistive)
2.0 Amps maximum for 100ms inrush
Output leakage current 0.5mA at 30VDC maximum
On response time
Off response time
0.2ms maximum
1.0ms maximum
Protection No internal fuses
