9-22 VersaMax® Modules, Power Supplies, and Carriers User's Manual – March 2003 GFK-1504K
9
IC200MDD845
Mixed Module, Output Relay 2.0A Isolated 8 Points
/ Input 24VDC Pos/Neg Logic Grouped 16 Points
Module Specifications
Module Characteristics
Points 1 group of 8 outputs
16 inputs (2 groups of 8)
Module ID 80088040
Isolation:
User input to logic (optical)
and to frame ground
Group to group
Point to point
250VAC continuous; 1500VAC for 1 minute
250VAC continuous; 1500VAC for 1 minute
Outputs: 250VAC continuous; 1500VAC for 1 minute
Inputs: none
LED indicators One green LED per point shows individual point on/off state.
OK LED indicates backplane power is present
Backplane current consumption 5V output: 270mA maximum. See graph
External power supply 0 to 125VDC, 5/24/125VDC nominal
0 to 265VAC (47 to 63Hz), 120/240VAC nominal
Thermal derating See diagram
Configuration parameters Input filter time
Input Characteristics
Input voltage 0 to +30VDC, +24VDC nominal
On state voltage
Off state voltage
+15 to +30VDC
0 to +5VDC
On state current
Off state current
2.0 to 5.5mA
0 to 0.5mA
On response time
Off response time
0.5ms maximum
Configurable filter time 0 ms, 1.0ms (default), or 7.0ms
Input impedance 10kOhms maximum
Output Characteristics
Output voltage 0 to 125VDC, 5/24/125VDC nominal
0 to 265VAC (47 to 63Hz), 120/240VAC nominal
Output voltage drop 0.3V maximum
Load current 10mA per point minimum
2.0A for 5 to 265VAC maximum (resistive)
2.0A for 5 to 30VDC maximum (resistive)
0.2A for 31 to 125VDC maximum (resistive)
Output leakage current Not applicable (open contact)
On response time
Off response time
10ms maximum
10ms maximum
Protection No internal fuses or snubbers
Relay type Fixed coil, moving armature
Contact type Silver alloy
Contact life See appendix B
