11-52 VersaMax® Modules, Power Supplies, and Carriers User's Manual – March 2003 GFK-1504K
11
IC200ALG331
Analog Output Module, 16 Bit Voltage/Current, 1500VAC Isolation, 4 Channels
Operation
The default parameters of this module can be used in many applications. The module can
be software-configured when it is installed in a VersaMax PLC system, or an I/O Station
controlled by a Network Interface Unit that is version 2.0 or above.
Output Defaults
The module requires both logic and module 24 volt power supplies to produce an output.
Subsequent loss of power or communication will produce output states as determined by
the configuration. These are:
Power and configuration states Output condition
Field power, no logic power, not configured All outputs 0
Field and logic power, not configured All outputs 0
Field and logic power, configured Outputs are scaled and follow program data
Module defaults due to loss of
communications or other cause.
Outputs are set to configured default: value or
Hold Last State.
In I/O Station with NIU, outputs are set to 0.
Loss of backplane power after configuration Outputs are set to Hold Last State if configured
for Hold Last State operation, or to 0 if “default”
was configured. A configured default value is not
available to the module if backplane power has
been lost.
In I/O Station with NIU, outputs set to 0.
Communication returns without loss of
Field Power
Outputs resume operation after configuration.
Calibration
The module is calibrated at the factory. For most applications, no further calibration is
required. It is possible to perform recalibration in either of the following ways:
By changing a module’s scaling so its scaled data agrees with metered values.
By sending the module a recalibration message as described in the PLC User's
Manual.
