A-6 VersaMax® Modules, Power Supplies, and Carriers User's Manual – March 2003 GFK-1504K

CPU or Expansion Receiver Module to Connector-Style I/O Carrier (Shown), Compact

Terminal-Style I/O Carrier, or Communications Carrier

.000.340in

8.6mm

.000

1.819in

46.2mm

689in REF

17.5mm

IC200CPU001

CPU or Expansion Receiver Module to Terminal-Style I/O Carrier

.340in

8.6mm

.000

1.819in

46.2mm

.689in REF

17.5mm

C200CHS002

.000

4.010in

101.9mm

IC200CPU001
