4-8 VersaMax® Modules, Power Supplies, and Carriers User's Manual – March 2003 GFK-1504K

IC200CHS003

Connector-Style I/O Carrier

The Connector-Style I/O Carrier (IC200CHS003) has a 36-pin connector for attaching an

I/O cable. It provides mounting, backplane communications, and field wiring for one I/O

module.

66.8mm

(2.63in)

133.4mm

(5.25in)

IND CONT EQ FOR HAZ LOC

CLASS I DIV 2 GROUPS ABCD

Ambient 60C

CLASS 1 ZONE 2 GROUP IIC

Ex nA IIC 0C <To<60C

Ex nV II Demko No. 98Y.125014

IC200CHS003

I/O CARRIER

CONNECTOR STYLE

The I/O module mounts vertically (perpendicular to the DIN rail) on this carrier.
