121
Section 5 Rear stabilizer bar assembly, strut rod components
Components
Replacement
1. Separate rear stabilizer bar assembly and strut rod components
(1) Remove the nut connecting the rear stabilizer bar and mount
(2) Remove the rear stabilizer bar retaining ring and the rubber ring
(3) Remove the 4 bolts connecting rear stabilizer bar and vehicle body
Rear Stabilizer Bar Rubber Bushing
Rear Stabilizer Bar Clamp
Rear Stabilizer Bar
Rear Stabilizer Bar
Retainer
Rear Stabilizer Bar
Rubber Ring
Rear Stabilizer Bar
Retainer
Rubber Ring
Bushing
Strut Rod Mount
Strut Rod Welding
Components
