349
î™– Take out the rear trunk carpet, spare tire cover board and the rear trunk miscelleaneous box. Screw the
spare tire press plate assembly to take out the spare tire.
2. Installation
1 Clip the rear trunk inside trim onto the corresponding hole in the reserve order of the removal;
2 Install the right rear and left rear combination lamp access hole cover;
3 Install the right and left speaker grill to the rear partition inside trim with a cross screwdriver;
4 Install the rear partition inside trim to the vehicle body;
5 Install the high mounted stop lamp and the C- pillar upper inside trim.
(XV) Engine Hood Inside Trim
Engine Hood Inside Trim Diagram:
Engine Hood Inside Trim
1. Engine Hood Inside Trim 2. E-Clip
1. Removal
1 Open the engine hood and gas spring;
2 Remove the clip and remove the engine hood inside trim
2. Installation
1 Open the installed engine hood and gas spring;
2 Align the corresponding hole position in the the engine hood inside trim and press the clip in by hand.
2
1
