359
Part V Body
Chapter 1 General Information
Section 1 Body Structure
An automobile body is mainly composed of the main body, removable sheet metal parts, interior and exterior
trim parts, and body accessories.
I. Main Body
The main body is mainly composed of the front sheet metal, cowl parts, floor assembly, LH/RH side wall
assembly, Rear back panel assembly, trunk shelf assembly and roof panel assembly, etc. by welding them
together, as shown in the Figure 5-1.
Figure 5-1 MAIN BODY
1 Front Sheet Metal, Cowl Parts 2 Roof Panel Assy. 3 LH/RH Side Wall Assy.
4 Rear Shelf Assy. 5 Rear Back Panel Assy. 6. Floor Assy.
