Geely CK MR479QA 2007 User Manual

116
Chapter 6 Rear Suspension System
Section 1 Rear Suspension System
Rear suspension structure description
This model uses strut independent rear suspension with stabilizer bar.
Rear suspension consists of the parallel front and rear double transverse arms, trailing rod, rear stabilizer bar
and rear strut assembly. The shock absorber and cone coil spring are arranged eccentrically.
See the table below for the major technical parameters of the rear suspension
Problem Symptoms Table
Use the table below to help you find the cause of the problem. The numbers indicate the priority of the likely
cause of the problem. Check each part in order. If necessary, replace these parts.
Items Parameter Items Parameter
Shock absorber operating
cylinder diameter /mm
￠
56 Camber -20´±30´
Shock absorber piston rod
diameter/mm
￠
18 Wheel toe-in/mm 1
～
5
Shock absorber stroke/mm 230mm
Remark: Wheel alignment parameter is at free load
Symptom Suspected Area
1. Tires (Worn or improperly inflated)
2. Wheel alignment (Incorrect)
3. Hub bearing (Worn or damaged)
4. Suspension parts (Worn or damaged)
1. Vehicle (Overloaded)
2. Spring (Stiffness small)
3. Shock absorber (Worn)
1. Tire (Worn or improperly inflated)
2. Wheel (not within specification)
3. Shock absorber (Worn)
1. Tire (Worn or improperly inflated)
2. Wheel alignment (Incorrect)
3. Shock absorber (Worn)
4. Wheel (not within specification)
1. Tire (Worn or improperly inflated)
2. Wheel alignment (Incorrect)
3. Shock absorber (Worn)
4. Suspension parts (Worn)
Abnormal tire wear
Deviation
Body Descent
Sways
Rear wheel shimmy
