Geely CK MR479QA 2007 User Manual

90
Chapter 2 Accelerator Pedal
Section 1 Accelerator Pedal
Components
Replacement
1. Remove the accelerator cable
Loosen the set nut attaching the accelerator cable to the accelerator
cable bracket on the engine, remove the accelerator cable from
the throttle valve rocker arm
2. Remove accelerator pedal
(1) Remove two set nut between the accelerator pedal
and vehicle body
(2) Separate the accelerator cable
3. Detach the accelerator cable
4.Install the accelerator cable and accelerator pedal assembly in the reverse order of the
Notice:
(1) Accelerator pedal assembly fixing bolt torque: 20~25N.m
(2) Properly adjust the position of the accelerator cable set screw to ensure the adequate
tension of the accelerator cable
(3) Check whether the accelerator control is flexible and reliable
Cowl Baffle
Hole Plug
Accelerator
Pedal Assembly
Accelerator Cable
Adjusting Nut
Connect
The Engine
above procedure.
