Section 6 Service Data For Body
I. Service Data For Body (Table 5-1)
TABLE 5-1 Service Data For Body
Content Service Data
Reshaping clearance between engine hood inner and
outer plate 3mm±0.5mm
Clearance between LH/RH fender and hoo
d
5mm(0,-1mm)
Clearance between LH/RH headlamp and hood 7mm±0.5m
m
Clearance between front bumper and fender
≤
1m
m
Clearance between LH/RH headlamps and bumper,
fender 5mm(0.-1mm)
Clearance between fender and LH/RH doors 5mm(0,-1mm)
，
Height error
≤
0.5mm
Clearance between hood and bumper 7mm±0.5m
m
Clearance between radiator grille and hood 0.5m
m
Cowl ventilator cover hole and wiper shaft are
homocentric. Coaxial Degree
N
o more than 2m
m
Clearance between door and side wal
l
5mm(0,-1mm)
Clearance between door and sill 7mm±0.5mm
Clearance between fuel fill port cover and side wall 3mm±0.5m
m
Clearance between rear bumper and side wall plate 1mm±0.5m
m
Clearance between Rear tail lamp and side wall plate 1mm±0.5m
m
Clearance between windshield and drip channe
l
4—5m
m
Glass is lower than drip channe
l
0.5—1m
m
Clearance between glass and roof panel 4.5—7mm and lower than 0.5—1m
m
Trunk lid folding edge, spot-welding interva
l
250—300mm Height of welding spot is no
more than 1m
m
Trunk lid inner plate flanging sides are higher than
outer plate 1—1.4m
m
Clearance between trunk lid and side wall plate 5mm(0,-1mm)
Clearance between trunk lid and rear combination
lamp 5mm(0,-1mm)
Clearance between trunk lid and bumper 7mm±0.5m
m
Height difference of parts which is bilateral symmetry
on the outside body
N
o more than 5m
m
Height of trunk lid limit block is proper. Height of the
sealing strip when the trunk lid is locked
12m
m
