Section 2 Light System Symptom Inspection
I. LIGHT SYSTEM PROBLEM SYMPTOMS TABLE
NOTES:
The table below can help you find the causes of malfunction. These figures show the most possible malfunc-
tions in order of priority. Inspect each part in the order given. If necessary, repair or replace these parts.
1. HEADLAMP AND TAIL LAMP
Symptom Suspected Area
1. Bulb
2. LH or RH headlamp fuse
3. Harness
1. Lamp switch assembly
2. Harness
1. Bulb
2. LH or RH headlamp fuse
3. Harness
1. Lamp switch assembly
2. Harness
1. Lamp switch assembly
2. Harness
1. Bulb
2. Harness
1. Bulb
2. Harness
1. Fuse
2. Light control switch
3. Harness
1. Beam control switch
2. Harness
“Low beam” dose not light (One side)
“Low beam” dose not light (All)
“High beam” dose not light (One side)
“High beam” dose not light (All)
Tail lamps on both sides do not light (Headlamp is
abnormal)
Light dose not flash (Dimmer)
Headlamp is dim
Only one side tail lamp lights
Tail lamps on both sides do not light (Headlamp is
normal)
To Next Page
