203
2. FRONT FOG LAMP SYSTEM
3. REAR FOG LAMP SYSTEM
Symptom Suspected Area
1. Fog lamp fuse
2. Front fog lamp relay
3. Light switch assembly
4. Harness
1. Bulb
2. Harness
Front fog lamp dose not light up with light control
switch HEADLAMP (Head lamp is normal).
Only one side front fog lamp dose not light
Symptom Suspected Area
1. Bulb
2. Light switch assembly
3. Harness
1. Bulb
2. Tail lamp fuse
3. Harness
1. Bulb
2. Harness
Rear fog lamp dose not light up with light
control switch on FRONT FOG LAMP (Small
lamp is normal).
Rear fog lamp dose not light up with light
control switch on FRONT FOG LAMP (Small
lamp is abnormal).
Only one side rear fog lamp dose not light
