217

Section 5 Rear Combination Lamp Replacement

I. REMOVAL

1. Remove rear trunk seal strip and interior trimming.

2. Remove the 3 mounting bolts (A, B, C as shown in the illustration).

3. Remove the rear combination lamp electrical connector.

4. Pull the rear combination lamp assembly backwards.

Seal Strip

Interior Trimming

Buckle and Plug

Electrical

Connecto
