Analog Meter
4. INSPECT FUEL LEVEL GAUGE
(1) Inspect resistance
When the fuel level gauge indicates no fuel, inspect the resistance between terminal A-12 and B-7 on the
combination meter connector.
Standard:
NOTICE:
Connector should be disconnected when measured.
5. INSPECT WATER TEMPERATURE GAUGE
(1) Inspect resistance
When the water temperature is indicated in the red area, inspect the resistance between terminal B-5 and
B-7 on the combination meter connector.
Tachometer (r/min) handy tachometer (r/min)
800 740—860
1000 900—1100
2000 1850—2150
3000 2800—3200
4000 3800—4200
5000 4800—5200
6000 5750—6250
Standard indication Resistance (Ω)
E 104—116
Warning point 90—100
1/2F 29—35
F
１
—
５
