208
(d) Inspect front and rear fog switch continuity
Inspect each terminal for continuity when the switch is on every position according to the table.
If it is not as specified, replace the switch.
2. BACK-UP LAMP SWITCH ASSEMBLY
Inspect back-up lamp switch continuity
Inspect continuity between the 2 terminals when the switch operates according to the table.
If it is not as specified, replace the switch.
3. BRAKE LAMP SWITCH ASSEMBLY
Inspect brake lamp switch assembly continuity
Inspect continuity between the 2 terminals when brake lamp switch operates
If it is not as specified, replace the switch.
4. HAZARD WARNING LAMP SWITCH ASSEMBLY
Inspect hazard warning lamp switch for continuity.
Inspect continuity between the 2 terminals when the switch operates
If it is not as specified, replace the switch.
Switch position Tested terminal Condition
OFF 5BB3-9NB4-9NB1 No continuity
Front fog lamp 5BB3-9NB4 Continuity
Rear fog lamp 5BB3-9NB1 Continuity
Switch position Tested terminal Condition
ON 1/2 Continuity
OFF 1/2 No continuity
Switch position Tested terminal Condition
ON (Gearshift lever is on REVERSE) 1/2 Continuity
OFF 1/2 No continuity
Switch position Tested terminal Condition
Depress on the brake pedal 1/2 Continuity
Release the brake pedal 1/2 No continuity
