298
evaporator (6) via the expansion valve (5) for compression and generates high temperature and pressure
vapor which then is cooled into liquid through the condenser (2) and dried in the receiver/drier (3), then
restrict the expansion valve and enable certain amount of refrigerant liquid to be vapored into low tempera-
ture and pressure vapor in the evaporator, meanwhile, absorb large amount of heat and perform heat ex-
change with the air sucked in by the blower, then distribute the cooled air to the vehicle compartments. Cycle
the operation until the compartments gets the desired temperature.
See Table 1 for the Refrigeration system parameter.
Table 1 Refrigeration system parameter
Parameter
Control the mixture of cool and hot air
Nominal Refrigeration/W 4200
Displacement/(mL/r) 108
Model SW-5H11
Electromagnetic Clutch Power Dissipation/W 45
SW-100/135
Maximum Airflow/(m
3
/h)
400
Airflow adjustment 4th Shift Manual
Motor Power Consumption/W 180
Dimension/mm 18×302×630
Heat Exchange/W 9400
Air Resistance/Pa
≤
156
Fan Motor Current/A
≤
8
Fan Motor RPM /(r/min) 2900±200
Dimension/mm 86×213×235
Refrigeration/W 4200
Thermal Expansion Valve Inner Balance 1.5 ton
4PK830
630±20
Refrigerant Fill/g
Blow er
Condenser
Evaporator
Drive belt
Item
Temperature adjustment method
Compressor
Lubricant /mL
