2. Instrument Panel Removal/Installation
(1) Remove the airbag actuator at the driver side.
(2) Remove the intermediate instrument panel.
(3) Remove the audio device
(4) Remove A/C control mechanism.
(5) Remove in the order below in the figure.
(6) The installation is in the reverse order of the removal.
Torque: 18.6--25.5 N.m
1 instrument panel wire harness
2 instrument panel cross member
3
instrument panel
1
2
3
