355
Rear Doorinside Trim
Rear Doorinside Trim Component:
1.Rear Doorinside Trim Board Assembly 2.Rear Door Lock Inner Handle Assembly
3.Controller
Trim Board 4.Door Handle 5.Set Screw
1.Rear doorinside trim board removal/installation
(1) Remove the set screw. (See Figure 5)
(2) Remove the rear door inside trim board assembly.
(3) Disassemble the inside trim board assembly as required
(4) The installation is in the reverse order of the removal.
1
2
3
4
5
