ADV200 SP • Quick start up guide - Specification and installation 65
Code Error message shown
on the display
Sub-code Description
52
53
54
55
Analog 1 Err
Analog 2 Err
Analog 3 Err
Analog 4 Err
Condition: If an analog measurement is out of the allowed range an “Analog X err” alarm is generated. This control is
only possible for 4-20 mA, PT100, PT1000, NI1000 probes. For temperature probes both short-circuits and power loss
on the cable are detected. For 4-20 mA probes only power loss on the cable is detected.
Analog 1 Err = Error on analog channel 1
Analog 2 Err = Error on analog channel 2
Analog 3 Err = Error on analog channel 1 of expansion card
Analog 4 Err = Error on analog channel 2 of expansion card
Solution: Check connections.
