gefran ADV200 SP Series User Manual

ADV200 SP • Quick start up guide - Specification and installation 81
ADV200-SP-5750 = 767 [30.2”] - ADV200-SP-5900/51100 = 784 [30.86”]
DETAIL B
DETAIL A
6.5
R3.25
13
19
(2:3)DETAIL B
6.5
R3.25
12
(2:3)DETAIL A
311 [12.24”]
220 [8.66”]
325 [12.8”]
868 [34.17”]
748 [29.45”]
730 [28.74”]
Figure 9.9.7: Size 5 dimensions (ADV200 SP-...-4)
311 [12.24]
265 [10.43]
190 [7.48]
325 [12.80]
ADV200-SP-5750-...-DC = 777 [30.59] ADV200-SP-5900/51100-...-DC = 801 [31.53]
747.5 [29.43]
730.4 [28.76]
45.5
DETAIL A
DETAIL B
6.5
12
R3.25
DETAIL A
SCALE 1:1
19
13
6.5
R3.25
DETAIL B
SCALE 1:1
Figure 9.9.8: Size 5 dimensions (ADV200 SP-...-4-DC)
