gefran VDI100 Series

Code Parameter Name / Range
01-16 Maximum output frequency of motor 2
5.0~599.0 Hz
01-17 Maximum output voltage of motor 2
230V: 0.1~255.0 V
400V: 0.2~510.0 V
01-18 Middle output frequency 2 of motor 2
0.0~599.0 Hz
01-19 Middle output voltage 2 of motor 2
230V: 0.0~255.0 V
400V: 0.0~510.0 V
01-20 Middle output frequency 1 of motor 2
0.0~599.0 Hz
01-21 Middle output voltage 1 of motor 2
230V: 0.0~255.0 V
400V: 0.0~510.0 V
01-22 Minimum output frequency of motor 2
0.0~599.0 Hz
01-23 Minimum output voltage of the motor 2
230V: 0.0~255.0 V
400V: 0.0~510.0 V
01-24 Base frequency of motor 2
5.0~599.0 Hz
01-25 Base output voltage of motor 2
230V: 0.0~255.0 V
400V: 0.0~510.0 V
01-26 V/f Curve Selection of Motor 2
0~FF
Note: Motor 2 V/f curve uses the same settings as motor 1, please refer to tables 4.4-A, 4.4-B and 4.4-C.
VDI100 • Instruction manual 137
