4.2.2. Keypad Menu Structure
Main Menu
The
VDI100 inverter main menu consists of two main groups (modes). The DSP/FUN key is used to switch
between the monitor mode and the parameter group mode.
Power On
Power-up
Monitor Mode Parameter Group Mode
DSP
FUN
DSP
FUN
Mode Description
Monitor Mode View inverter status, signals and fault data.
Parameter Group Mode Access to available parameter groups.
All the available parameter groups are listed in the Parameter Group Mode use the up and down keys to select
a group and press Read/Enter key to access its parameters.
Parameter Group Mode
Parameter Mode
Parameter Edit Mode
DSP
FUN
DSP
FUN
READ
ENTER
READ
ENTER
Select parameter
Change parameter setting
Select parameter group
Fig.4.2.2.1ParameterGroupStructure
Note ! - Always perform an auto-tune on the motor before operating the inverter in vector control (sensorless vector or flux vector).
Auto-tuning mode will not be displayed when the inverter is running or when a fault is active.
- To scroll through the available modes, parameter groups or parameter list press and hold the up or down key.
Monitor Mode
In monitor mode inverter signals can be monitored such as output frequency, output current and output voltage,
etc…) as well as fault information and fault trace. See Fig 4.2.2.2 for keypad navigation.
Power ON
Monitor
Freq Ref
12-17=000.00Hz
12-18=0000.0A
12-16=005.00Hz
Flt Freq Ref
12-15=000.00Hz
Monitor
Monitor
12-17=000.00Hz
12-18=0000.0A
Flt DC Voltage
12-17=000.00Hz
12-18=0000.0A
00 Basic Func.
01 V/F Pattern.
02 Motor Parameter
Group
DSP
FUN
DSP
FUN
DSP
FUN
DSP
FUN
12-14=0000.0V
Fig4.2.2.2MonitorMode
52 VDI100 • Instruction manual
