11.2. AC Line Reactors
An AC line reactor can be used for any of the following:
- Capacity of power system is much larger than the inverter rating.
- Inverter mounted close to the power system (in 33ft / 10 meters).
- Reduce harmonic contribution (improve power factor) back to the power line.
- Protect inverter input diode front-end by reducing short-circuit current.
- Minimize overvoltage trips due to voltage transients.
Please select the AC line reactor based on the inverter
overload according to the following table.
Table11.2.1ListofACLineReactors
Class Model
HD Overload (150%) ND Overload (120%)
Choke type Code
Dimensions
WxHxd (Weight)
Choke type Code
Dimensions/Weight
WxHxd mm (kg)
230V
3ph
1007 LR3-005 S7FF7 150 x 155 x 85 mm; (6 kg) LR3y-2075 S7AB6 150 x 155 x 79 mm; (4.9 kg)
1015 LR3-011 S7FF6 180 x 182 x 130 mm; (8 kg) LR3y-3150 S7AB8 150 x 169 x 85 mm; (5.5 kg)
2022 LR3y-2075 S7AB6 150 x 155 x 79 mm; (4.9 kg) LR3-022 S7FF4 180 x 182 x 130 mm; (7.8 kg)
2037 LR3y-3150 S7AB8 150 x 169 x 85 mm; (5.5 kg) LR3-030 S7FF3 180 x 160 x 185 mm; (8.2 kg)
2055 LR3-022 S7FF4 180 x 182 x 130 mm; (7.8 kg) LR3-037 S7FF2 180 x 160 x 185 mm; (9.5 kg)
3075 LR3-030 S7FF3 180 x 160 x 185 mm; (8.2 kg) LR3-055 S7FF1 180 x 180 x 185 mm; (12 kg)
4110 LR3-037 S7FF2 180 x 160 x 185 mm; (9.5 kg) LR3-055 S7FF1 180 x 180 x 185 mm; (12 kg)
4150 LR3-055 S7FF1 180 x 180 x 185 mm; (12 kg) LR3-090 S7D19 300 x 205 x 265 mm; (30 kg)
4185 LR3-055 S7FF1 180 x 180 x 185 mm; (12 kg) LR3-090 S7D19 300 x 205 x 265 mm; (30 kg)
5220 LR3-090 S7D19 300 x 205 x 265 mm; (30 kg) LR3-090 S7D19 300 x 205 x 265 mm; (30 kg)
400V
3ph
1007 LR3y-1015 S7AAE 120 x 125 x 65 mm; (1.8 kg) LR3y-1030 S7AB3 120 x 125 x 65 mm; (1.9 kg)
1015 LR3y-1022 S7AAF 120 x 125 x 65 mm; (1.9 kg) LR3y-2040 S7AAG 120 x 125 x 65 mm; (2 kg)
1022 LR3y-1030 S7AB3 120 x 125 x 65 mm; (1.9 kg) LR3y-2075 S7AB6 150 x 155 x 79 mm; (4.9 kg)
2037 LR3y-2040 S7AAG 120 x 125 x 65 mm; (2 kg) LR3y-3110 S7AB7 150 x 155 x 79 mm; (5 kg)
2055 LR3y-2075 S7AB6 150 x 155 x 79 mm; (4.9 kg) LR3y-3150 S7AB8 150 x 169 x 85 mm; (5.5 kg)
3075 LR3y-3110 S7AB7 150 x 155 x 79 mm; (5 kg) LR3-022 S7FF4 180 x 182 x 130 mm; (7.8 kg)
3110 LR3y-3150 S7AB8 150 x 169 x 85 mm; (5.5 kg) LR3-030 S7FF3 180 x 160 x 185 mm; (8.2 kg)
3150
4150
LR3-022 S7FF4 180 x 182 x 130 mm; (7.8 kg) LR3-030 S7FF3 180 x 160 x 185 mm; (8.2 kg)
4185 LR3-022 S7FF4 180 x 182 x 130 mm; (7.8 kg) LR3-037 S7FF2 180 x 160 x 185 mm; (9.5 kg)
4220 LR3-030 S7FF3 180 x 160 x 185 mm; (8.2 kg) LR3-055 S7FF1 180 x 180 x 185 mm; (12 kg)
5300 LR3-037 S7FF2 180 x 160 x 185 mm; (9.5 kg) LR3-055 S7FF1 180 x 180 x 185 mm; (12 kg)
5370 LR3-055 S7FF1 180 x 180 x 185 mm; (12 kg) LR3-090 S7D19 300 x 205 x 265 mm; (30 kg)
5450 LR3-055 S7FF1 180 x 180 x 185 mm; (12 kg) LR3-090 S7D19 300 x 205 x 265 mm; (30 kg)
5550 LR3-090 S7D19 300 x 205 x 265 mm; (30 kg) LR3-090 S7D19 300 x 205 x 265 mm; (30 kg)
6750
(*)
6900
71100
71320
71600
Note: AC reactors listed in this table can only be used for the inverter input side. Do not connect AC reactor to the inverter
output side.
(*) 400V class 75kW ~ 160kW have a built-in DC reactors. If required by the application an AC reactor may be added.
