03 - External Digital Input and Output Parameters
Code Parameter Name / Range
03-00 Multi-function terminal function setting – S1
03-01 Multi-function terminal function setting – S2
03-02 Multi-function terminal function setting – S3
03-03 Multi-function terminal function setting – S4
03-04 Multi-function terminal function setting – S5
03-05 Multi-function terminal function setting – S6
03-06 Multi-function terminal function setting – S7
03-07 Multi-function terminal function setting – S8
0: 2-Wire sequence (ON: Forward run command)
1: 2-Wire sequence (ON: Reverse run command)
2: Multi-speed/position setting command 1
3: Multi-speed/position setting command 2
4: Multi-speed/position setting command 3
5: Multi-speed/position setting command 4
6: Forward jog run command
7: Reverse jog run command
8: UP frequency increasing command
9: DOWN frequency decreasing command
10: Acceleration/deceleration time selection 1
11: Inhibit Acceleration/deceleration Command
12: Main/ Alternative Run Switch Function
13: Main/ Alternative Frequency Switch Function
14: Emergency stop (decelerate to zero and stop)
15: External Baseblock Command(rotation freely to stop)
16: PID control disable
17: Fault reset (RESET)
18: Reserved
19: Speed Search 1 (from the maximum frequency)
20: Manual energy saving function
21: PID integral reset
22~23: Reserved
24: PLC input
25: External fault
26: 3-Wire sequence (Forward/Reverse command)
27: Local/Remote selection
28: Remote mode selection
29: Jog frequency selection
30: Acceleration/deceleration time selection 2
31: Inverter overheating warning
32: Sync command
33: DC braking
34: Speed Search 2 (from the frequency command)
35: Time function input
36: PID Soft start disabled
37: Traversing operation
38: Upper Deviation of traverse operation
39: Lower Deviation of traverse operation
40: Switching between motor 1/motor 2
41: PID Sleep
42: PG disable
43: PG integral reset
44: Mode switching between speed and torque
45: Negative torque command
46: Zero-Servo Command
47: Fire Mode (Forced Operation mode)
48: KEB acceleration
49: Parameter writing allowable
50: Unattended Start Protection (USP)
51: Mode switching between speed and position
52: Multi Position Reference Enable
53: 2-Wire Self Holding Mode (Stop Command)
54: Reserved
55: Reserved
56: Reserved
57: Reserved
58: Safety Function
59: Reserved
60: Reserved
61: Reserved
62: EPS Function
142 VDI100 • Instruction manual
