gefran VDI100 Series User Manual

63: Reserved
64: Reserved
65: Short-circuit braking
Refer to the multi-function digital input and related parameters in the following gure 4.4.16.
Figure4.4.16Multi-functiondigitalinputandrelatedparameters
S1
S2
S3
S4
S5
S6
S7
S8
Related Parameters
03-00
24VG
03-01
03-02
03-03
03-04
03-05
03-06
03-07
Table4.4.6Multi-functiondigitalinputsetting(03-00to03-07)(“O”:Enable,“X”:Disable)
Value
Function
Description
Control mode
Name LCD Display V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
0
2-wire type (Forward oper-
ation)
2-Wire (FWD-RUN)
2- wire (ON : Forward opera-
tion command).
O O O O O O O
1
2-wire type (Reverse oper-
ation)
2-Wire (REV-RUN)
2- wire (ON : Reverse opera-
tion command).
O O O O O O O
2
Multi-speed/position setting
command 1
Muti-Spd/Pos Ref 1
Multi-Speed Reference /
Position Reference 1
O O O O O O O
3
Multi-speed/position setting
command 2
Muti-Spd/Pos Ref 2
Multi-Speed Reference /
Position Reference 2
O O O O O O O
4
Multi-speed/position setting
command 3
Muti-Spd/Pos Ref 3
Multi-speed Reference /
Position Reference 3
O O O O O O O
5
Multi-speed/position setting
command 4
Muti-Spd/Pos Ref 4
Multi-speed Reference /
Position Reference 4
O O O O O O O
6 Forward jog run command FJOG
ON: Forward operation in jog
mode (00-18).
O O O O O O O
7 Reverse jog run command RJOG
ON: Reverse operation in jog
mode (00-18).
O O O O O O O
8
UP frequency increasing
command
UP command
ON: Command of output
frequency increasing (only
used by support of DOWN
command).
O O O O O O O
9
DOWN frequency decreasing
command
DOWN command
ON: Command of output fre-
quency decreasing (only used
by support of UP command).
O O O O O O O
10
Acceleration/deceleration time
selection 1
Acc/Decel Time Selection 1
Acceleration/deceleration time
selection command 1
O O O O O O O
11
Inhibit Acceleration/decelera-
tion Command
ACC/DEC Inhibit
ON: Acceleration/ deceleration
prohibition
O O O O O O O
12
Main/ Alternative Run Switch
Function
Run Change Sel
Run Command Source is set
in parameter of alternative
frequency command (00-03)
O O O O O O O
VDI100 • Instruction manual 143
