in sec.
(05-17) x (05-01) (05-19) x [(05-02)-(05-01)] (05-21) x [(05-03) – (05-02)]
(01-02) (01-02) (01-02)
a = b = c =
(05-24) x [(05-03) – (05-04)] (05-26) x (05-04) (05-25) x (05-05)
(01-02) (01-02) (01-02)
d = e = f = in sec.
(05-27) x (05-05) (05-27) x (05-06) (05-19) x (05-06)
(01-02) (01-02) (01-02)
g = h = i = in sec.
Code Parameter Name / Range
05-01 Frequency setting of speed-stage 0
0.0~599.00 Hz
05-17 Acceleration time setting for multi speed 0
0.0~6000.0 s
05-18 Deceleration time setting for multi speed 0
0.0~6000.0 s
05-19 Acceleration time setting for multi speed 1
0.0~6000.0 s
05-20 Deceleration time setting for multi speed 1
0.0~6000.0 s
05-21 Acceleration time setting for multi speed 2
0.0~6000.0 s
05-22 Deceleration time setting for multi speed 2
0.0~6000.0 s
05-23 Acceleration time setting for multi speed 3
0.0~6000.0 s
05-24 Deceleration time setting for multi speed 3
0.0~6000.0 s
05-25 Acceleration time setting for multi speed 4
0.0~6000.0 s
05-26 Deceleration time setting for multi speed 4
0.0~6000.0 s
05-27 Acceleration time setting for multi speed 5
0.0~6000.0 s
05-28 Deceleration time setting for multi speed 5
0.0~6000.0 s
05-29 Acceleration time setting for multi speed 6
0.0~6000.0 s
05-30 Deceleration time setting for multi speed 6
0.0~6000.0 s
05-31 Acceleration time setting for multi speed 7
0.0~6000.0 s
05-32 Deceleration time setting for multi speed 7
0.0~6000.0 s
05-33 Acceleration time setting for multi speed 8
0.0~6000.0 s
05-34 Deceleration time setting for multi speed 8
0.0~6000.0 s
184 VDI100 • Instruction manual
